Alpha Silencer III 16" Porcelain Bridge Saw Blade — Marmo
Pickup currently unavailable at Dynamic Stone Tools Warehouse (Manassas Park, VA)
Description
Description
Alpha Silencer III 16" Porcelain Bridge Saw Blade — Marmo
The Alpha Silencer III 16" porcelain bridge saw blade delivers the quietest, smoothest, and longest-lasting cut in its class. Diamond segments are matrix-tuned for porcelain slabs, large-format ceramic tile, and crystallized glass, and the steel core is laser-welded with Alpha's patented noise-dampening core that reduces cutting noise by up to 50% versus conventional bridge-saw blades. This variant is engineered for Marmo/MarmoElettromeccanica bridge saws.
Key Features
- Silencer III noise-dampening laser-welded steel core — up to 50% quieter cuts
- Diamond matrix optimized for porcelain slabs, large-format ceramic tile, and crystallized glass
- Marmo arbor configuration: 60mm Marmo arbor with drive pin
- Maximum operating speed: 2800 RPM
- Wet-cutting use only — for bridge saws
- Premium long-life formulation engineered by Alpha Professional Tools
| Property | Detail |
|---|---|
| SKU | SLW161MP |
| Brand | Alpha Professional Tools |
| Series | Silencer III |
| Diameter | 16" |
| Material to cut | Porcelain |
| Machine compatibility | Marmo |
| Arbor | 60mm Marmo arbor with drive pin |
| Maximum RPM | 2800 RPM |
| Cutting type | Wet only |
| Net weight | 6.8 lb |
| Country of origin | Korea |
- Verify your bridge saw spindle speed does not exceed the blade's maximum RPM rating.
- Mount the blade on the saw arbor (60mm Marmo arbor with drive pin); confirm the rotation arrow matches the spindle direction.
- Tighten the arbor flange to manufacturer torque spec; never use impact tools on the flange nut.
- Engage water cooling at a steady 1.5–2 GPM flow on both sides of the blade BEFORE the cut.
- Begin the cut at reduced feed and let the blade self-find its cutting depth.
- Recommended feed rate for porcelain: start at 30 in/min and adjust by feel.
- After cutting, let the blade spin out under water for 10–15 seconds to flush slurry.
This blade is engineered for Marmo/MarmoElettromeccanica bridge saws. The 60mm Marmo arbor with drive pin configuration fits any compatible bridge saw spindle. For wet cutting of porcelain slabs, large-format ceramic tile, and crystallized glass only. Do not use on dry cutters, angle grinders, or handheld saws.
A: Alpha's 3rd-generation noise-dampening core uses a sandwich-laminated steel construction that absorbs cutting vibration and reduces audible noise by up to 50% compared to a conventional one-piece steel blade core.
A: This blade's diamond matrix is tuned for porcelain slabs, large-format ceramic tile, and crystallized glass. Cutting other materials will work but will shorten blade life and reduce edge quality. For other materials, choose the matching Silencer III variant.
A: Yes. All Silencer III bridge-saw blades require continuous water flow. Dry cutting will damage the segments and void the warranty.
A: Life varies with material density, feed rate, water flow, and operator technique. In typical porcelain production, expect a multi-fold life improvement over standard bridge-saw blades when used at recommended RPM and feed.
Always use wet cutting. Wear ANSI Z87+ safety glasses, hearing protection, and cut-resistant gloves. Verify the blade RPM rating exceeds your saw's spindle speed. Inspect the blade before each use for cracks or segment damage.
