Aardwolf WSDA01 Water Swivel Drill Adaptor R 1/2
Pickup currently unavailable at Dynamic Stone Tools Warehouse (Manassas Park, VA)
Description
Description
Aardwolf WSDA01 Water Swivel Drill Adaptor — R 1/2 in
The Aardwolf WSDA01 is a water-feed swivel adaptor for wet diamond core drilling. It delivers cooling water through the spinning drill chuck to the diamond core bit. Built for stone, concrete, and masonry contractors running wet core bits on hand drills and stands.
Features
- R 1/2 in threaded connection for standard core bit shanks
- Internal water swivel passes coolant through the spinning shaft
- Reduces diamond bit wear and slab chipping during wet drilling
- Compact body fits handheld drills and lightweight drill stands
- Replaceable seals support long service life
- Brass and steel construction for shop durability
- Thread the WSDA01 onto the drill spindle until snug.
- Connect the inlet hose to a clean cold water supply.
- Mount the diamond core bit to the lower R 1/2 in thread.
- Open the water supply before starting the drill.
- Begin drilling at low pressure and let the diamonds cut.
- Wear eye protection, gloves, and a dust mask throughout the cut.
| Property | Detail |
|---|---|
| Brand | Aardwolf |
| Part Number | WSDA01 |
| Thread | R 1/2 in |
| Function | Water swivel drill adaptor |
| Application | Wet diamond core drilling |
Use with R 1/2 in shank diamond core bits on hand drills and lightweight drill stands. Suitable for granite, marble, concrete, and masonry wet drilling.
Manufacturer Features & Specifications
General
The Aardwolf Water Swivel Adapters are made to fit Aardwolf Water Swivels with a 1/2" male thread connector and machined from stainless steel.
Specifications
The Aardwolf Water Swivel Adapters are made to fit Aardwolf Water Swivels with a 1/2" male thread connector and with a range of models compatible with various sizes of core bits. The diamond core drill bite is held firmly in place by two small grub screws.
The Water Swivel Adapter WSDA01 is made to fit Water Swivel WS01 with a 1/2" male thread connector and is compatible with core bits with a 10mm/0.4” spindle. The diamond core drill bite is held firmly in place by two small grub screws.
The Water Swivel Adapter WSDA02 is made to fit Water Swivel WS02 with a 1/2" male thread connector to a male 14mm thread that accepts diamond core bits with a female 14mm connector. (Prevalent in Europe).
The Water Swivel Adapter WSDA03 is made to fit Water Swivel WS03 with a 1/2" male thread connector to a male 5/8” thread that accepts diamond core bits with a female 5/8” connector. (Prevalent in North America).
The Water Swivel Adapter WSDA05 is made to fit Water Swivel WS05 with a 1/2" male thread connector to a female 14mm thread that accepts diamond core bits with a male 14mm connector.
The Water Swivel Adapter WSDA06 is made to fit Water Swivel WS06 with a 1/2" male thread connector to a female 5/8” thread that accepts diamond core bits with a male 5/8” connector.
