Aardwolf Industries  |  SKU: SPVL100

Aardwolf SPVL-100 Lightweight Portable Vacuum Lifter

$2,732.96 USD
Shipping calculated at checkout.

Pickup available at Dynamic Stone Tools Warehouse (Manassas Park, VA)

Usually ready in 2 hours

Description

SPVL100 Small Pneumatic Vacuum Lifter

The Aardwolf SPVL-100 Small Pneumatic Vacuum Lifter is a vacuum lifter for handling smooth, non-porous material. It is rated at 265 lb (120 kg). Power/actuation: Compressed air (no electricity). Built from all aluminum incl. suction pad. Unit weight 25 lb (11.5 kg).

Features

  • 265 lb (120 kg) lifting capacity
  • Powered by Compressed air (no electricity)
  • Operates at 58-87 PSI (4-6 bar)
  • Clip-in battery alarm, ON/OFF valve, energy saver
  • Weighs 25 lb (11.5 kg)
  • All aluminum incl. suction pad
Property Detail
Brand Aardwolf
Lifting Capacity 265 lb (120 kg)
Weight 25 lb (11.5 kg)
Operating Pressure 58-87 PSI (4-6 bar)
Vacuum Reservoir 0.26 gal (1 liter)
Power Source Compressed air (no electricity)
Construction All aluminum incl. suction pad
Vacuum Generator Venturi (no moving parts)
Safety Clip-in battery alarm, ON/OFF valve, energy saver
Country of Origin Vietnam
  1. Inspect the vacuum pad seal for cuts, grit, or compression set before each shift.
  2. Connect the air/battery supply — 58-87 PSI (4-6 bar).
  3. Seat the pad flat on clean, sound, non-porous material with no chips or seams under the seal.
  4. Draw vacuum and wait for the gauge to reach the safe zone before taking any load.
  5. Lift slowly and keep the load low; never stand or pass under a suspended load. Never exceed the rated 265 lb (120 kg).
  6. Set the material down fully, then release vacuum and vent the pad.
