Alpha Cordless 3-3/8" Saw Blade for Glass Wet Cordless Saw Blade for Glass
Pickup available at Dynamic Stone Tools Warehouse (Manassas Park, VA)
Usually ready in 2 hours
Alpha Cordless 3-3/8" Saw Blade for Glass Wet Cordless Saw Bla...
Description
Description
Alpha® Cordless 3-3/8" Wet Saw Blade for Glass
The Alpha® Cordless Saw Blade for Glass is engineered for wet cutting of mirror, sheet glass and glass tile using battery-powered saws. Its smooth continuous diamond rim delivers chip-free finishes, making it ideal for switch-box cut-outs, trim work and decorative glass installations. Compatible with cordless saws from Makita, Panasonic and Skil.
Features
- Wet use only — continuous water flow required
- Smooth continuous rim for chip-free cutting on glass and mirror
- Ideal for switch-box cut-outs and trim work
- Perfect for mirror, sheet glass and glass tile
- Specifically designed for cordless / battery-powered saws
- Maximum depth of cut: 53/64"
| Part No. | Diameter | Arbor | Max RPM | UPC |
|---|---|---|---|---|
| BG03AL | 3-3/8" (86 mm) | 15 mm | 1,500 | 749173450280 |
- Mount the blade so the diamond bond tails point OPPOSITE the rotation direction (see sticker on blade).
- Confirm the saw RPM does not exceed 1,500 RPM.
- Set up continuous water feed at the cutting edge — never dry cut.
- Cut steadily without forcing; let the blade do the work.
- If the cut speed slows, re-dress the blade with a dressing stone or soft concrete block to expose fresh diamond.
3-3/8" (86 mm) diameter — Continuous rim wet diamond blade — BG03AL
| Part No. | BG03AL |
| UPC | 749173450280 |
| Size | 3-3/8" (86 mm) diameter |
| Type | Continuous rim wet diamond blade |
| Max RPM | 1,500 RPM |
| Recommended For | Mirror, sheet glass and glass tile — wet cutting only |
| Packaged Weight | 0.10 lbs |
| Package Dimensions | 4.5" × 4.5" × 0.5" |
| Commodity Code | 8202.91.0000 |
| Country of Origin | Japan |
| Property | Detail |
|---|---|
| Blade Thickness | 0.9 mm (0.035") |
| Arbor | 15 mm |
| Maximum RPM | 1,500 |
| Maximum Depth of Cut | 53/64" (~21 mm) |
| Rim Type | Continuous smooth diamond rim |
| Application | Wet cutting only |
| Recommended Materials | Mirror, sheet glass, glass tile |
| Compatible Tools | Cordless saws from Makita, Panasonic, Skil |
Which way do I install the blade on my tool?
The proper blade direction is shown on the sticker label on the blade. Position it so the diamond bond tails point opposite the rotation direction.
What materials can I cut with this blade?
This blade is designed for glass, mirrors and decorative glass tile.
Which battery-powered tools are compatible?
Makita, Panasonic and Skil cordless saws are the tools of choice for this 3-3/8" glass blade.
Can I use this blade for dry cutting?
No. Wet diamond blades must be used with continuous water to prevent heat buildup. Dry running will damage the blade.
How do I restore cutting speed if it slows down?
Re-dress the blade with a soft abrasive such as a dressing stone or concrete block to expose fresh diamond when the surface glazes over.
What is the maximum RPM?
This 3-3/8" diameter blade should not exceed 1,500 RPM.
What is the arbor size?
The arbor size of this blade is 15 mm.
What is the maximum depth of cut?
The maximum depth of cut is 53/64" (~21 mm).
No product-specific videos are currently available from the manufacturer or DST.
⚠ WARNING: This product can expose you to Nickel, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov.. Always wear appropriate PPE.
